ActiGraph wGT3X-BT
The wGT3X-BT is ActiGraph’s flagship activity monitor, used by researchers around the world to capture and record continuous, high resolution physical activity and sleep/wake information. The Bluetooth® Smart wGT3X-BT features ActiGraph’s validated 3-axis accelerometer and digital filtering technology and includes integrated wear time and ambient light sensors.
Request QuoteDeclaration of Conformity / Declaration of Conformity (Brazil)
Cross Generation Accuracy / Calibration
ACCESSORIES & USB CABLES SOLD SEPARATELY
ONLY COMPATIBLE WITH ACTILIFE VERSION 6.8.1 AND LATER.
U.S. federal law restricts this device to sale by or on the order of a physician.
ActiGraph Objective Measures
The ActiGraph wGT3X-BT captures and records high resolution raw acceleration data, which is converted into a variety of objective activity and sleep measures using publicly available algorithms developed and validated by members of the academic research community. Available measures include:
- Raw Acceleration (G's)
- Activity Counts
- Energy Expenditure
- MET Rates
- Steps Taken
- Physical Activity Intensity
- Activity Bouts
- Sedentary Bouts
- Body Position
- Sleep Latency
- Total Sleep Time
- Wake After Sleep Onset
- Sleep Efficiency
- Ambient Light
- Heart Rate R-R Intervals*
ActiGraph wGT3X-BT Features
Bluetooth® Smart
ActiGraph wGT3X-BT monitors are powered by Bluetooth® Smart technology and support a variety of wireless features, including heart rate monitoring, proximity detection, and communication with ActiGraph’s suite of mobile applications for iOs and Android devices.
Wear Time Sensor
A wear time sensor on the back of the monitor uses capacitive touch technology to automatically detect when a wrist worn device has been removed for simplified compliance monitoring and data cleaning.
Ambient Light Sensor
The wGT3X-BT includes an integrated ambient light sensor that delivers lux values alongside activity information, providing insights into the relationship between the subject environment and activity and sleep behaviors.
ActiGraph wGT3X-BT Specifications
The ActiGraph wGT3X-BT captures and records high resolution human activity information using a solid state 3-axis MEMS accelerometer and our proprietary filtering algorithm. The wGT3X-BT is fully backward compatible with previous device models to ensure data comparability for our existing clients.
Dimensions
4.6cm x 3.3cm x 1.5cm
Weight
19 grams
Sample rate
30-100 Hertz
Dynamic range
+/- 8G
Battery life
25 days*
Memory
4GB
Data storage
180 days
Communication
USB, Bluetooth® Smart
Wear location
Wrist, waist, ankle, thigh
Water resistance
1 meter, 30 minutes
Warranty
1 Year
Regulatory Requirements
The ActiGraph wGT3X-BT is an FDA cleared Class II medical device within the United States and a Class I medical device within the European Union that abides by the regulatory requirements listed below:
- EN60601-1-Medical Device General Safety Requirements
- Part 15.109 (US) – Radiated Emission Limits of Unintentional Radiators
- Part 15.249 (US) – Radiated Emission Limits of Intentional Radiators
- ICES-003 (Canada) – Interference Causing Equipment Standards for a Digital Apparatus.
- ActiGraph is compliant with IEC standards for “Type BF Applied Part”
The ActiGraph wGT3X-BT is water resistant in accordance with IEC 60529 IP27, or immersion in one (1) meter of water for up to 30 minutes.
All ActiGraph products are manufactured Lead Free and are RoHS Compliant.
U.S. federal law restricts this device to sale by or on the order of a physician.
